FRAME // Specialized M5 Aluminum, 29 Trail HT Geometry, integrated down tube battery, enclosed internal cable, Command Post routing, 148mm spacing
FORK // SR Suntour XCM32, 47mm offset, 15x110mm thru-axle, 100mm travel
FRONT WHEEL // Hand-built wheel assembly
REAR WHEEL // Hand-built wheel assembly
FRONT HUB // Specialized, sealed cartridge bearings, 15x110mm spacing, 28h
REAR HUB // Specialized, sealed cartridge bearings, 12x148mm thru-axle, 28h
SPOKES // Stainless, 14g
RIMS // Specialized XC 29, 25mm internal width, disc-specific
INNER TUBES // Standard, Presta valve
FRONT TYRE // Ground Control, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
REAR TYRE // Ground Control, GRID casing, GRIPTON® compound, 2Bliss Ready, 29x2.3"
CRANKSET // 2D cold-forged alloy, custom offset, 165mm
CHAINRINGS // 32T, steel ring
SHIFT LEVERS // Shimano Alivio, 9-speed w/ Optical Gear Display
REAR DERAILLEUR // Shimano Alivio, Shadow Design, SGS cage, 9-speed
CASSETTE // Shimano HG201, 9-speed, 11-36t
CHAIN // KMC e9S.NPBK, e-bike chain, 9-speed w/ Missing Link™
FRONT BRAKE // Shimano BR-MT200, hydraulic disc, 180mm
REAR BRAKE // Shimano BR-MT200, hydraulic disc, 180mm
HANDLEBARS // Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, XS 720mm, S-XL 750mm, 31.8mm clamp
GRIPS // Specialized Body Geometry XC, clamp-on
STEM // Specialized, 3D-forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
SADDLE // Body Geometry Myth 155 XS, Body Geometry Henge 143 S/M/L/XL, steel rails
SEATPOST // Specialized 2-bolt head, forged alloy, 8mm offset, micro-adjust, 30.9mm
SEAT BINDER // Alloy, bolt-type, 34.9mm
SWAT // Specialized Z-Cage w/EMT Cage Mount MTB Tool
MOTOR // Specialized 1.2 E, custom Rx Street-tuned motor, 250W nominal
UI/REMOTE // Specialized Handlebar Trail Remote w/walk-assist
BATTERY // Specialized M1-400, integrated Trail Display, ANT+/Bluetooth® module, 400Wh
CHARGER // Custom Specialized 42V2A Charger w/ Rosenberger plug, AC power cord included
WIRING HARNESS // Custom Specialized wiring harness
PEDALS // Specialized Dirt
