frame
E5 Aluminum, bottom bracket motor mount, fully integrated &lockable downtube battery, internal cable routing, lock and front rack mount
seat binder
SEAT COLLAR, KCNC, SPL-SC02-349-02, EXTRUDED, 7075-T73, 34.9MM, 10B21, BLACK ZINC BOLT, BOLT CLAMP TYPE
fork
Rockshox Recon Silver RL, 110mm travel, Motion-Control
stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
handlebars
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, S 720mm, M-XL 750mm
grips
Specialized Trail Grips, Lock-on
saddle
Rivo Sport, steel rails, 155mm
seatpost
TranzX Dropper, 30.9mm, S: 100mm, M-XL: 120mm
front brake
SRAM G2 RS, 4-piston caliper, hydraulic disc, 200mm
rear brake
SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm
rear derailleur
SRAM GX, long cage, 11-speed
shift levers
SRAM S700, single-click lever
cassette
SRAM PG-1130, 11-speed, 11-42t
chain
KMC e11T, 11-speed w/ Missing Link™
crankset
Custom alloy forged crankarms
chainrings
Praxis, 36T, 104BCD
rims
Stout XC 29, 25mm internal width, disc-specific
front hub
Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
rear hub
Specialized alloy rear hub disc, sealed cardridge bearings, 6-bolt, 12x148mm thru-axle, 32h
spokes
DT Swiss Industry
front tyre
Ground Control, 2Bliss Ready, 29x2.35"
rear tyre
Ground Control, 2Bliss Ready, 29x2.35"
inner tubes
Presta, 48mm valve
charger
Custom charger, 42V4A w/ Rosenberger plug, 100-240V
- wiring harness
Custom wire harness
UI/remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
motor
Specialized 2.2, 90Nm torque, custom tuned motor, 250W nominal
- battery
Specialized U2-710, alloy casing, state of charge display, 710Wh
bell
Simple bell
bike lock
Turbo System Lock
pedals
Specialized platform pedal
SWAT
Specialized Stealth Stem, Display Insert
weight
18.8kg (41 lb, 7.2 oz)
weight size
MD
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
