FRAME
Specialized M4 Premium Aluminium, Trail 6Fattie Geometry, fully-butted w/ smooth welds, tapered head tube, tapered seat tube, forged 160mm disc mounts, 148mm thru-axle dropouts, replaceable alloy derailleur hanger
FORK
Manitou Magnum Comp 650+, S: 100mm travel, M/L/XL: 120mm travel, Absolute+ damper, rebound adjust, tapered steerer, 15x110mm thru-axle, disc mount
HEADSET
1-1/8" upper, 1-1/2" lower, threadless, Campy style, cartridge bearings
STEM
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise
HANDLEBARS
Specialized Stout XC, flat bar, double-butted 6061 alloy, 9-degree backsweep, 4-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle, S/M: regular thickness, L/XL: XL thickness
FRONT BRAKE
SRAM DB3 Trail, 4-piston, semi-metallic pads, 180mm rotor
REAR BRAKE
SRAM DB3, dual piston, semi-metallic pads, 160mm rotor
BRAKE LEVER
SSRAM DB3, hydraulic, reach adjust
REAR DERAILLEUR
SRAM GX Type 2.1, 10-speed, long cage
SHIFT LEVERS
SRAM GX, 10-speed, trigger
CASSETTE
Custom Sunrace, wide range, 10-speed, 11-40t
CHAIN
KMC X10L, 10-speed, w/ reusable MissingLink
CRANKSET
Specialized Stout XC Pro, forged alloy, 148-specific chain line, PF30, alloy spindle, 30T, 76mm BCD spider
BOTTOM BRACKET
Samox, PF30, sealed cartridge
PEDALS
Alloy, 1 pc. body, 9/16", w/ reflectors
RIMS
WTB Scraper i45 650b, double-wall, 45mm inner width, 18mm deep, TCS tubeless compatible, sleeved, 24/28h
FRONT HUB
Specialized Stout XC Pro 110, disc, alloy, cartridge bearings, 15x110mm thru-axle, 24h
REAR HUB
Specialized Stout XC Pro 148, disc, alloy, loose ball bearings, 12x148mm thru-axle, 28h
SPOKES
Stainless, butted, 2.0/1.8/2.0mm, black
FRONT TYRE
Specialized 6Fattie Ground Control, 60TPI, 2Bliss Ready, folding bead, 650bx3.0"
REAR TYRE
Specialized 6Fattie Ground Control, 60TPI, 2Bliss Ready, folding bead, 650bx3.0"
SADDLE
Body Geometry Henge Comp, thin padding, hollow Cr-Mo rails, 143mm
SEATPOST
TranzX YSP03 dropper, internal cable routing, remote lever, 30.9mm, S: 100mm travel, M/L/XL: 120mm travel
SEAT BINDER
Alloy, 31.8mm
