FRAME // FACT 11m, X-Wing layout, full carbon chassis and rear end, All Mountain Geometry, SWATâ„¢ Door integration, threaded BB, fully enclosed internal cable routing, ManFu link, oversized pivot bearings, alloy link & adjustable shock extension, 12x148mm dropouts, replaceable derailleur hanger, 160mm of travel
FORK // Öhlins RXF 36, 29/6Fattie, Single-Tube design, air spring w/ adjustable 3rd chamber, adjustable low-speed compression, adjustable rebound, 15x110mm thru-axle, 51mm offset, 160mm of travel
REAR SHOCK // Custom Öhlins STX, Single-Tube design, Rx All Mountain Tune, AUTOSAG, adjustable compression & rebound damping, 216x57mm
FRONT HUB // Specialized, sealed cartridge bearings, 15x110mm spacing, 24h
REAR HUB // DT Swiss 350, Star Ratchet, 36t engagement, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
SPOKES // DT Swiss Revolution
RIMS // Roval Traverse Carbon 29, hookless carbon, 30mm inner width, 24/28h, tubeless ready, hand-built
INNER TUBES // Standard, Presta valve
FRONT TYRE // Butcher, GRID casing, Gripton compound, 2Bliss Ready, 29 x 2.3"
REAR TYRE // Butcher, GRID casing, Gripton compound, 2Bliss Ready, 29 x 2.3"
CRANKSET // Truvativ Descendant, carbon, Boostâ„¢ 148, 170mm crankarm, 24mm spindle
CHAINRINGS // Steel, 30T
BOTTOM BRACKET // SRAM GXP, XR 73
SHIFT LEVERS // SRAM X01 Eagle, trigger, 12-speed
REAR DERAILLEUR // SRAM X01 Eagle, 12-speed
CASSETTE // SRAM X01 Eagle, 12-speed, 10-50t
CHAIN // SRAM X01 Eagle, 12-speed w/ PowerLock
FRONT BRAKE // SRAM Code R, 4-piston caliper, hydraulic disc, metallic pads, 200mm rotor
REAR BRAKE // SRAM Code R, 4-piston caliper, hydraulic disc, metallic pads, 180mm rotor
HANDLEBARS // Specialized DH, 7050 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 800mm, 31.8mm clamp
GRIPS // Specialized Sip Grip, half-waffle, S/M: regular thickness, L/XL: XL thickness
STEM // Specialized Trail, 3D forged alloy, 4-bolt, 6-degree rise
SADDLE // Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST // Command Post IRcc WU, 12-position micro-height adjustable, alien head design, bottom mount cable routing, remote adjust SRL lever, 34.9mm, 150mm of travel
SEAT BINDER // Alloy, 38.6mm
PEDALS // Specialized Platform, Cr-Mo, 9/16" spindle
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying.
