FRAME // M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel
FORK // RockShox BoXXer Ultimate 29, Charger 2.1 Damper, DH DebonAir spring, short crown, 20x110mm thru-axle, 56mm offset, 200mm of travel
REAR SHOCK // RockShox Super Deluxe Ultimate DH Coil, external low speed compression, external rebound adjust, Trunnion mount, 225x75
FRONT HUB // Alloy, sealed cartridge bearings, 20x110mm, 28h
REAR HUB // DT Swiss 350, SRAM XD freehub, 6-bolt disc, high-low flange, sealed cartridge bearings, 12x148mm spacing, 28h
SPOKES // DT Swiss Competition, stainless steel, 14g
RIMS // Roval Alloy DH, 29 front, 27.5 rear, 28mm internal width, 28h, tubeless ready
INNER TUBES // Standard, Presta Valve
FRONT TYRE // Butcher BLCK DMND, 29x2.3"
REAR TYRE // Butcher BLCK DMND, 27.5x2.3"
CRANKSET // SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
CHAINRINGS // 34T
BOTTOM BRACKET // SRAM DUB, 83mm
SHIFT LEVERS // SRAM X01 DH, trigger, 7-speed
REAR DERAILLEUR // SRAM X01 DH, 7-speed, trigger
CASSETTE // SRAM X01 DH, 7-speed, 10-24t
CHAIN // Sram PC1130 w/ Powerlink, 11-speed
FRONT BRAKE // SRAM Code RSC, 4-piston caliper, hydraulic disc, 220mm
REAR BRAKE // SRAM Code RSC, 4-piston caliper, hydraulic disc, 200mm
HANDLEBARS // Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, 800mm, 35.0mm
GRIPS // Deity, Knuckleduster, Black
STEM // Descendant 35mm Direct Mount Stem, 50mm length
SADDLE // Body Geometry Henge DH, hollow titanium rails, 130mm
SEATPOST // Thomson, alloy, straight, 12-degree clamp
SEAT BINDER // Alloy, 34.9mm
