frame
M5 Alloy chassis and rear-end, asymmetrical design, 29/27.5" Trail Geometry with S-Sizing, SWAT™ Door integration, head tube angle adjustment, horst pivot BB adjustment, threaded BB, fully enclosed internal cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 150mm of trave
rear shock
Rock Shox Super Deluxe Ultimate, Rx Trail Tune,RC2T Damper, Hydraulic Bottom Out control , S1:210x50mm, S2-S6:210x55mm
fork
RockShox Lyrik Ultimate, Charger 3 RC2 W/ButterCups, 15x110mm, 44mm offset, S1: 150mm of travel, S2-S6: 160mm of travel
stem
Deity, 35.0mm
handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, 780mm width
grips
Deity Grips
saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
seatpost
OneUp, Dropper Post-V2, MMX lever, 34.9 (S1:120mm, S2/S3:150mm, S4: 180mm, S5/S6: 210mm)
front brake
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
rear brake
SRAM Code RS, 4-piston caliper, hydraulic disc, 200mm Centerline
rear derailleur
SRAM GX Eagle, 12-speed
shift levers
SRAM GX, trigger, 12-speed
cassette
Sram XG-1275, 12-speed, 10-52t
chain
SRAM GX Eagle, 12-speed
crankset
SRAM GX Eagle Alloy, DUB, 165/170/175mm, 32t
chainrings
32T
bottom bracket
SRAM DUB, BSA 73mm, Threaded
rims
Roval Traverse 29F/27.5R Alloy, 30mm inner width, hand-built, 2Bliss Ready
front hub
Roval, sealed cartridge bearings, 15x110mm spacing, 28h
rear hub
Roval DT Swiss 370, Ratchet LN, SRAM XD driver body, 12mm thru-axle, 148mm spacing, 28h
spokes
DT Swiss Competition Race
front tyre
Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
rear tyre
Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, 27.5 x 2.3"
inner tubes
Standard, Presta valve
seat binder
Alloy, 38.6mm
weight
15.55kg (34 lb, 4.5 oz)
weight size
S4
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
