Frame
M5 Alloy chassis and rear-end, Trail Geometry, horst pivot geo adjustment, threaded BB, internal cable routing with external rear brake option, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 170mm of travel
Seat Binder
Alloy, 38.6mm
Rear Shock
RockShox Super Deluxe Select Coil, external rebound adjust, hydraulic bottom out, 230x62.5mm
Fork
RockShox BoXXer 29, Charger 3 RC damper, adjustable low-speed compression, adjustable rebound, 20x110mm thru-axle, 44mm offset, 180mm of travel
Saddle
Body Geometry Henge DH, hollow Cro-Mo rails, 130mm
SeatPost
Specialized 2-bolt head, forged alloy, 5mm offset, micro-adjust, 34.9mm
Stem
Descendant 35mm Direct Mount Stem, 50mm length
Handlebars
Specialized, 6061 alloy, 6-degree upsweep, 8-degree backsweep, 30mm rise, S2: 780mm, S3-S5: 800mm
Grips
Deity Lockjaw
Rear Brake
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 200mm
Front Brake
SRAM Maven Bronze, 4-piston caliper, hydraulic disc, 220mm
Rear Derailleur
SRAM GX DH, 7-speed, trigger
Shift Levers
SRAM GX DH, trigger, 7-speed
Cassette
SRAM GX DH, 7-speed, 11-24t
Chain
SRAM PC1110 w/ Powerlink™
Crankset
SRAM DESCENDANT DH, DUB, alloy, Direct, 34T ring, 55mm chainline, 165mm
Bottom Bracket
SRAM DUB Threaded Wide
Rims
Roval Alloy DH, 28mm internal width, tubeless ready. Front: 29", 28H, Rear: 27.5", 32H
Front Hub
Alloy, sealed cartridge bearings, 20x110mm, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
Spokes
DT Swiss Industry
Front Tire
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
Inner Tubes
Standard, Presta valve
Product ID
221356
Weight
17.18kg (37 lb, 14 oz)
Weight Size
S3
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
