FRAME
FACT 9m carbon front triangle, EVO geometry, FACT TM construction, M5 rear triangle, tapered headtube, carbon PF30 BB, full internal shift/brake/post routing, 142mm dropouts, sealed cartridge bearing pivots, replaceable derailleur hanger, 120mm travel
SWAT
Bottle cage, EMT Tool, and Top Cap Chain Tool w/ SWAT Technology
REAR SHOCK
Custom FOX Float CTD Factory, w/ AUTOSAG, Climb, Trail, Descend settings w/ Trail and reb adj., Kashima coating, 197x51mm
FORK
RockShox Pike 29, Solo Air spring, tapered alloy steerer, comp and reb adj., 15mm thru-axle, 120mm travel
HEADSET
1-1/8 and 1-1/2" threadless, Hella Flush style upper with 1-1/2" lower, cartridge bearings
STEM
Specialized XC, 3D forged alloy, 4-bolt, 6-degree rise, 31.8mm clamp
HANDLEBARS
Specialized XC Mini Riser, 7050 butted alloy, 750mm wide, 10mm rise, 8-degree backsweep, 6-degree upsweep, 31.8mm
GRIPS
Specialized Sip Grip, light lock-on, half-waffle aramid-infused, S/M: regular, Others: XL thickness
FRONT BRAKE
Custom Formula T1 S, metallic pad, S/M: 180mm, Others: 200mm rotor
REAR BRAKE
Custom Formula T1 S, metallic pad, S/M: 160mm, Others: 180mm rotor
BRAKE LEVERS
Custom Formula T1 S, hydraulic disc, tool-less pad contact (FCS) and reach adj., SRAM compatible MiXmaster shifter mounts
FRONT DERAILLEUR
REAR DERAILLEUR
SRAM X01, 11-speed
SHIFT LEVERS
SRAM X01, 11-speed, trigger
CASSETTE
SRAM X01, 11-speed, 10-42
CHAIN
SRAM XG 1195, 11-speed, hollow plates/pins, PowerLink
CRANKSET
Custom SRAM carbon S-2200, 32T XX1 style single ring, PF30 spindle, removable spider, S: 170mm, Others: 175mm
CHAINRINGS
32T
BOTTOM BRACKET
SRAM PF30, OS press-in bearings, sealed cartridge
PEDALS
RIMS
Roval Traverse 29, alloy disc, 28mm wide, 32h
FRONT HUB
Roval Traverse 29, 15mm thru-axle end caps, 32h
REAR HUB
Roval Traverse 142+, XX1 driver body, 12mm thru-axle, 32h
SPOKES
DT Swiss Super Comp, 2.0/1.65/1.8 stainless
FRONT TYRE
Specialized Butcher Control, 2Bliss Ready, 29x2.3", foldable aramid bead, dual- compound, 60TPI
REAR TYRE
Specialized Purgatory Control, 2Bliss Ready, 29x2.3", foldable aramid bead, dual-compound, 60 TPI
INNER TUBES
PV Ultra Light
SADDLE
Body Geometry Henge Comp, hollow Cr-Mo rails, 143mm
SEATPOST
Specialized Command Post IR, 3-position, internally routed adjustable height w/ air spring, remote operated, single bolt head, 30.9mm, S:100mm, Others: 125mm travel
SEAT BINDER
7050 hard anodised alloy collar, single bolt, 34.9mm
