With its cutting-edge technology and race-ready design, the Merida Scultura Gen 5 Road Bike sets a new standard in road biking performance.
With its cutting-edge technology and race-ready design, the Merida Scultura Gen 5 Road Bike sets a new standard in road biking performance.
Merida

2025 Merida Scultura 9000 Road Bike - Red/Dark Red/Black

£4,999.00 £5,800.00 14% off
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2025 Merida Scultura 9000 Road Bike - Red/Dark Red/Black

Season:2025

Brand:Merida

Code:P-Q150

Merida Scultura Road Bike – 5th Generation: High-End Performance

Experience top-tier cycling with the fifth generation Merida Scultura Road Bike, featuring a lightweight CF5 carbon frame, Reynolds carbon wheelset, and the advanced 2x12 Shimano Ultegra Di2 groupset with hydraulic disc brakes. This high-performance road bike has been rigorously tested and validated by Team Bahrain Victorious, securing victories on mountain stages of the Tour de France and Vuelta a España even before its official launch.

CF5 Carbon Frame and Fork: The ultra-lightweight carbon frame and fork provide a perfect blend of strength, rigidity, and reduced weight, enhancing overall ride efficiency.

Shimano Ultegra Di2 2x12 Groupset: Offers precise, electronic shifting for smooth and reliable gear changes.

Shimano Ultegra Hydraulic Disc Brakes: Equipped with Disc Cooler Technology for superior stopping power and reduced brake fade.

Reynolds BL 46 Pro DB Carbon Wheelset: Paired with Continental GP5000S TR 28c tyres, this wheelset delivers exceptional performance, durability, and comfort.

Fully Integrated Carbon Cockpit: Integrates handlebars and stem for improved aerodynamics and a sleek appearance.

Merida S-Flex Carbon Seat Post: Designed for enhanced comfort and vibration damping.

The Gen 5 Scultura takes the bike's renowned lightweight agility and rider comfort to new heights. It now incorporates advanced aerodynamics from the Reacto model, featuring race-proven geometry that enhances speed and efficiency without sacrificing comfort. The bike's superior aerodynamic design, combined with its compliance and comfort, ensures a fresh and dynamic ride, particularly beneficial for final sprints and demanding climbs.

  • Frame: Superlight CF5 Carbon
  • Groupset: Shimano Ultegra Di2 2x12
  • Brakes: Shimano Ultegra Hydraulic Disc with Disc Cooler Technology
  • Wheelset: Reynolds BL 46 Pro DB Carbon with Continental GP5000S TR 28c Tyres
  • Cockpit: Fully Integrated Carbon
  • Seat Post: Merida S-Flex Carbon

With its cutting-edge technology and race-ready design, the Merida Scultura Gen 5 sets a new standard in road biking performance.

Technical Information
  • FRAME
    CF5 V carbon - Premium fibres for lightweight and performance, race geometry. Internal cable routing, 142 x12mm axle standard, flat mount rear brakes with Disc Cooler, 1 1/2" to 1 1/4" headtube. Pressfit 86.5 BB Standard, Max tyre size - 30c
  • GEARS
    24
  • FORK
    Scultura CF5 Disc; full carbon; Max tyre size: 700 x 30c - Disc cooler technology
  • SHIFTERS
    Shimano Ultegra Di2
  • FRONT DERAILLEUR
    Shimano Ultegra Di2; FD-R8150
  • REAR DERAILLEUR
    Shimano Ultegra Di2; RD-R8150
  • BOTTOM BRACKET
    SM-BB72-41B, Pressfit 86.5
  • CHAIN
    Shimano CN-M8100-12
  • CHAINSET
    Shimano Ultegra; 52-36 tooth chainset; Crank length - 165mm (XXS), 170mm (XS), 172.5mm (S/M/L), 175mm (XL)
  • CASSETTE
    Shimano CS-R8101; 11-30 teeth; 12 speed
  • BRAKE LEVER
    Shimano Ultegra
  • FRONT BRAKE
    Shimano Ultegra; Hydraulic disc brake caliper with Shimano CL800; 160mm rotor
  • REAR BRAKE
    Shimano Ultegra; Hydraulic disc brake caliper with Shimano CL800; 160mm rotor
  • GRIPS
    Merida Expert
  • HANDLEBAR
    Team SL 1P Integrated; carbon; 380mm (XXS-XS-S), 400mm (M-L-XL)
  • STEM
    Team One-Piece Integrated; carbon - Length - 90mm (XXS-XS), 100mm (S), 110mm (M-L), 120mm (XL)
  • HEADSET
    Merida Team SL (OP-203 neck)
  • SADDLE
    Scratch M5 with V-mount adapter; includes Merida minitool
  • SEATPOST
    Merida Team SL; 27.2mm diameter; 15mm layback; Carbon; S-Flex
  • WHEEL SIZE
    700c
  • RIMS
    Part of wheelset - Reynolds BL 46 Expert DB; 21mm inner rim width; 41mm rim depth; Carbon; Tubeless ready (tubeless tape and valves included)
  • SPOKES
    Part of wheelset
  • FRONT HUB
    Part of wheelset - Reynolds BL 46 Expert DB, 100 x 12mm; Centerlock
  • REAR HUB
    Part of wheelset - Reynolds BL 46 Expert DB; 142 x 12mm; Centerlock; Shimano HG
  • FRONT TYRE
    Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready
  • REAR TYRE
    Continental Grand Prix 5000S TR; 700 x 28C; Kevlar bead; tubeless ready
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
Sizing Information

SIZING

Size in ft4'11" - 5'2"5'3" - 5'5"5'5" - 5'8"5'9" - 5'11"6'0" - 6'2"6'3" - 6'7"
Size in cm150 - 158cm159 - 165cm166 - 173cm174- 182cm183 - 189cm190 - 200cm
Bike SizeXXSXSSMLXL

GEOMETRY

SculturaXXSXSSMLXL
Seat Tube435mm458mm481mm501mm521mm550mm
Top Tube Horizontal520mm535mm545mm560mm575mm590mm
Head Tube Length105mm112mm128mm140mm155mm176mm
Head Tube Angle70.5°72°72.5°73.5°73.5°74°
Head Tube Angle74.5°74°74°73.5°73°73°
Chain Stays408mm408mm408mm408mm408mm408mm
Bottom Bracket Drop70mm70mm66mm66mm66mm66mm
Fork Length385mm385mm385mm385mm385mm385mm
Standover Height721mm745mm765mm782mm800mm823mm
Stack517mm529mm542mm557mm571mm593mm
Reach377mm384mm390mm395mm400mm409mm
Wheelbase985mm983mm990mm990mm999mm1010mm
