Frame
All new Levo 4 frame, 150mm travel, w/SWAT storage, side entry battery, fork travel up to 180mm
Fork
FOX FLOAT 36 Rhythm, GRIP damper, two position Sweep adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel
Rear Shock
FOX FLOAT X Performance with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever, LSR adjustment
Seat Binder
Alloy, 38.6mm
Stem
Alloy Trail Stem, 35mm bar bore
Saddle
Bridge Comp, Hollow Cr-mo rails, 155/143mm
Handlebars
Specialized, 6000 series alloy, 6-degree upsweep, 8-degree backsweep. S2: 780 width, 30mm rise: S3-S4: 800 width, 35mm rise: S5-S6: 800 width, 50mm rise
Grips
Specialized Trail Grips
Seatpost
X-Fusion Manic, infinite adjustable, two-bolt head, bottom mount cable routing, remote SLR LE lever, 34.9, S2: 125mm, S3: 170mm, S4-S6: 190mm
Crankset
SRAM S1000 Crankset, Integrated Guard, 55mm Chainline, 155mm
Rear Derailleur
SRAM S1000 Eagle Transmission Derailleur
Chain
SRAM GX Eagle Transmission Flattop Chain
Cassette
SRAM XS-1270 Transmission Cassette, 12spd, 10-52t
Shift Levers
SRAM AXS POD Controller
Chainrings
SRAM T-type ring, 34T
Front Brake
SRAM Maven Bronze, 4-piston caliper, hydraulic disc
Rear Brake
SRAM Maven Bronze, 4-piston caliper, hydraulic disc
Rims
Specialized 29, hookless alloy, 30mm inner width, tubeless ready
Front Hub
Alloy, sealed cartridge bearings, 15x110mm thru-axle, 28h
Rear Hub
Alloy, sealed cartridge bearings, 12x148mm thru-axle, 32h
SWAT
SWAT internal downtube storage
Front Tyre
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, LR, 29x2.3"
Rear Tyre
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, LR, 27.5x2.3"
Inner Tubes
Standard, Presta Valve
Spokes
DT Swiss Industry
Motor
All New Specialized 3.1 Motor, 101Nm torque, 666W power
Battery
840wh battery
UI/Remote
All New Mastermind TCU, 2.2" highres screen, fully customizeable ith Specialized app, Apple Find My integrated in display
Charger
Specialized 4amp charger
Wiring Harness
Specialized wiring harness
Weight
24.41 kg (53 lb, 13.0 oz)
Weight Size
S4
