Frame
All new Levo 4 frame, 150mm travel, w/SWAT storage, side entry battery, fork travel up to 180mm
Fork
FOX FLOAT 38 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, 160mm of travel
Rear Shock
Fox Float X Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, 210x55mm
Seat Binder
Alloy, 38.6mm
Stem
Industry 9 A35 Moutain stem, 35mm clamp, 40mm length
Saddle
Bridge Mimic Expert, ti rail
Handlebars
RaceFace Era Carbon, riser bar, 5-degree upsweep, 8-degree backsweep, S2:20mm Rise, S3-S6:40mm Rise, 800mm
Grips
Deity Lockjaw grips
Seatpost
Bike Yoke Revive Max 3.0 Dropper post. S2:125mm, S3:160mm, S4: 185mm, S5/S6:213mm
Crankset
SRAM XO Alloy crank, 155mm, ISIS interface
Rear Derailleur
SRAM X0 Eagle Transmission
Chain
SRAM X0
Cassette
SRAM XO 1295, 12 speed, 10-52
Shift Levers
SRAM AXS POD Controller
Chainrings
SRAM 34t T-Type chainring, 104 BCD, steel
Front Brake
SRAM Maven Silver, 4-piston caliper, hyd. disc, 220mm HS2 Rotor
Rear Brake
SRAM Maven Silver, 4-piston caliper, hydr. disc, 200mm HS2 Rotor
Front Wheel
Roval Traverse HD 29", hookless carbon, 30mm inner width, tubeless ready, DT Swiss 350, 15x110, 28h
Rear Wheel
Roval Traverse HD 27.5", hookless carbon, 30mm inner width, tubeless ready, DT Swiss 350, 12x148, 32h
SWAT
SWAT internal downtube storage
Front Tyre
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tyre
Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 27.5x2.3"
Inner Tubes
Standard 40mm PV 29/27.5x1.75-2.4
Motor
All New Specialized 3.1 Motor, 101Nm torque, 666W power
Battery
840wh battery
UI/Remote
All New Mastermind TCU, 2.2" highres screen, fully customizeable with Specialized app, Apple Find My integrated in display
Charger
Specialized 4amp charger
Wiring Harness
Specialized wiring harness
Weight
23.94kg (52 lb, 12.5 oz)
Weight Size
S4
