The Merida Silex Carbon Gravel Bike is equipped with Shimano's GRX400 2x10 groupset and powerful hydraulic disc brakes, offering a top-tier ride for gravel enthusiasts.
The Merida Silex Carbon Gravel Bike is equipped with Shimano's GRX400 2x10 groupset and powerful hydraulic disc brakes, offering a top-tier ride for gravel enthusiasts.
Merida

2024 Merida Silex 4000 Gravel Bike - Bronze/Gold/Black

£1,699.00 £2,250.00 24% off
Pre-Order

With Pre-Order, you can purchase the latest items added to our store in advance of them arriving with us.

Your Pre-Order is prioritised (at no additional charge); meaning that as soon as the product arrives with us, we can wrap it straight back up; ready for collection via Click & Collect or despatch to you — it often never even hits the stock room shelves!

Pre-Launch

With Pre-Launch, the date when we expect to receive the product ourselves is still a little too hazy to be confident in accepting Pre-Orders.

So, instead, you can submit your email address against the item you are interested in and we will email you as soon as stock arrives on the system.

Estimated Delivery & Collection Dates

Estimated Delivery & Collection Dates are given on Pre-Order and Pre-Launch products. They are for indication purposes only and can change at any time without notice.

The dates we provide are based on indications given by our suppliers. Whenever we get updated information from our suppliers we will endeavour to update the Estimated Delivery & Collection Dates provided on product pages.

We estimate this will be ready for despatch to you or collection via Click & Collect on Undetermined

2024 Merida Silex 4000 Gravel Bike - Bronze/Gold/Black

Season:2024

Brand:Merida

Code:P-P445

The Merida Silex Carbon Gravel Bike is equipped with Shimano's GRX400 2x10 groupset and powerful hydraulic disc brakes, offering a top-tier ride for gravel enthusiasts. Designed with a second-generation frame, the Silex delivers the perfect balance between off-road capability and versatile adventure riding.

  • MTB-Inspired Gravel Geometry: Built with modern mountain bike-inspired geometry for enhanced off-road handling, featuring a longer top and head tube with a shorter stem for nimble, confidence-inspiring control.
  • Lightweight Carbon Frame: The carbon frame reduces weight while maintaining strength, providing a smooth ride on varied terrains.
  • Revised Fork Design: Gen 2 features a refined fork, allowing for suspension upgrades without affecting geometry, plus a visually more appealing front end with a shorter head tube.
  • Shimano GRX400 Groupset: The gravel-specific Shimano GRX400 2x10 groupset ensures precise shifting and reliable performance.
  • Hydraulic Disc Brakes: Equipped with 180mm rotors and hydraulic disc brakes for powerful, reliable stopping power. Calipers are mounted on the chainstay for better brake force dissipation and a sleek flat-mount fit.
  • CNCd Disc Cooler Fins: On carbon models, calipers rest on CNCd aluminium Disc Cooler fins, reducing operating temperatures by up to 35%, essential when fully loaded on long rides.
  • Adventure-Ready: Five sets of bottle bosses, internal routing for dropper posts, and dynamo system compatibility make the Silex perfect for long-distance adventures and bikepacking.
  • Proven Off-Road Capability: The Silex’s enhanced off-road performance is demonstrated by Matej Mohoric’s victory at the 2023 Gravel World Championships.

With a slacker head angle and wider tyres, the second-generation Merida Silex Carbon Gravel Bike is built for those who seek the road less traveled, offering comfort, versatility, and adventure-ready performance.

Technical Information
  • FRAME
    CF2 carbon II, gravel geometry for stable but nimble handling. Tapered head tube Inboard disc mounts. Threaded BB, 142 x 12mm axle standard, disc cooler technology, Max tyre size 700 x 45c (42c with mudguards)
  • FORK
    Silex CF2 II; Full carbon; tapered steerer, 100 x 12mm axle standard; Max tyre size: 700 x 45c (42c with mudguards)
  • GEARS
    20
  • SHIFTERS
    Shimano GRX400
  • FRONT DERAILLEUR
    Shimano GRX400
  • REAR DERAILLEUR
    Shimano GRX400
  • CHAIN
    KMC X10
  • CHAINSET
    Shimano GRX600; 46-30 tooth chainset. Crank length: 170mm (XS,S), 172.5mm (M), 175mm (L,XL)
  • CASSETTE
    Shimano CS-HG50; 11-36 teeth; 10 speed
  • BRAKE LEVER
    Shimano GRX400
  • FRONT BRAKE
    Shimano GRX400 hydraulic disc brake caliper with Shimano RT10 180mm rotor
  • REAR BRAKE
    Shimano GRX400 hydraulic disc brake caliper with Shimano RT10 180mm rotor
  • GRIP
    Merida Road Expert
  • HANDLEBAR
    Merida Expert GRII; aluminium; Width: 400mm (XS,S), 420mm (M) , 440mm (L/XL)
  • STEM
    Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise. Stem length: 80mm all sizes
  • HEADSET
    Merida-8158 Semi Integrated HS
  • SADDLE
    Merida Comp SL with V-mount; including Merida minitool
  • SEATPOST
    Merida Expert CC; 27.2mm diameter; 15mm lay back; Carbon
  • WHEEL SIZE
    700c
  • RIMS
    Merida Expert SL II; 23mm inner rim width; 25mm rim depth; aluminium; Tubeless ready (tubeless tape and valves not included)
  • SPOKES
    Black stainless
  • FRONT HUB
    Joytech D981SB; 100x12mm; 32 spokes; centerlock with Merida Expert TR axle
  • REAR HUB
    Joytech D872SB; 142x12mm; 32 spokes; centerlock with Merida Expert TR axle including removable 6/4mm allen key
  • FRONT TYRE
    Maxxis Rambler; 700 x 45C; Kevlar bead, folding; TR; EXO
  • REAR TYRE
    Maxxis Rambler; 700 x 45C; Kevlar bead, folding; TR; EXO
  • OTHER
    Fidlock Integrated Base & Merida Bottle
As with any product, specification is subject to change without prior notification. You are advised to confirm current specification before buying. Please note that this bike does not come with pedals.
Sizing Information

SIZING

Size in ft5'3" - 5'5"5'4" - 5'9"5'7" - 5'11"5'10" - 6'2"6'1" - 6'5"
Size in cm162 - 167cm165 - 177cm173- 185cm181 - 192cm188 - 200cm
Bike SizeXSSMLXL

GEOMETRY

SilexSMLXL
Seat Tube470mm500mm530mm560mm
Top Tube Horizontal565mm580mm600mm620mm
Head Tube Length150mm170mm190mm210mm
Head Tube Angle69.5°69.5°69.5°69.5°
Head Tube Angle74.5°74.5°74.5°74.5°
Chain Stays430mm430mm430mm430mm
Bottom Bracket Drop75mm75mm75mm75mm
Fork Length415mm415mm415mm415mm
Standover Height771mm798mm825mm852mm
Stack588mm607mm626mm645mm
Reach402mm412mm426mm441mm
Wheelbase1065mm1082mm1104mm1126mm
